IM-M1202D Anti-shock 100 Amp 2 Pole Remote Control Bistable Latching Relay with Auxiliary Contacts

Share :
Product parameters

Prouduct Details

IVY is specialized in the research, development, and manufacturing of high powered, high quality, highly reliable latching relays. We offer latching relays from 32A to 200A for both single, dual and three phase switching purposes. Our relays are designed to meet the industry's highest performance standard and it offers the best value in the Metering Market. We develop the product using innovative ways to save money and power for both consumers and producers of electricity. We are adhered to provide the best product with the lowest failure rate in the industry.

IVY Metering IM-M1202D 100A 2 phase relay are newly launched! Smaller in size, lower contact resistance, and permanent magnetic immunity up to 500mT.

IM-M1202D 100 Amp Bistable Latching Relay with Auxiliary Contacts


Product Advantages

100A two sets of contacts switching capability

Small size, high reliability, compact structure

Resistance to external static magnetic field up to 400mT/500mT

Strong anti-shock/vibration ability and low contact resistance

Built-in small motor driven, with auxiliary switch

In accordance with IEC 62055-31 IEC 62052-11:2020 UC3

Custom assemblies available with flexible wire, copper straps, CT, and with integrated shunt


Product Parameters

Basic Parameter

dimension

34.5*46.7*18mm

weight

≈46g

ambient temperature

-40~+85

Contact Parameter

Contact material

AgSnO2

Contact form

2A/2B

contact resistance

0.6mΩDC6~24V1A

Maximum switching current

100A

Maximum switching voltage

250VAC

Performance parameters

Rated voltage

12VDC

Motor resistance(R±15%

32Ω

Motor power consumption

4.5W

vibration

1.5mm(double amplitude),10~55Hz

Anti-shock resistance

1000m/s² (100G)

Insulation resistance

1000MΩ(500VDC

dielectric strength

motor to contacts

4000VAC,50/60Hz1min

across open contacts

2000VAC,50/60Hz1min

Short circuit current withstand capability

6000A50/60Hz10ms

pulse time

50ms~80msAdvise

pull-in time

45ms

release time

45ms

Electrical life

10000cylcle(resistive load 100A 230VAC

Mechanical life

100000cylcle


Product Dimension



TYPICAL APPLICATION:
Mainly used for prepayment electric energy meters, RS485 meters with the break & make function used in centralized meter reading system;
It might also be used for combination switches of electiric power factor compensation switch-capacitor, home appliances and automatic control devices.
