Product parameters
1.Product Details
800 series of electric meter counter is a cheap, low-cost mechanical counter.
Plastic and metal types can be optional. Its main features as follow:
1)Display digits: 6-digit or 7-digit black wheel;
2)0-9 character display; Number ratio: 200:1;
3)Long service life, Driving voltage is generally 3.0-5.5V, mainly designed for Russia market.
Beside They are widely used for:
1.Multi-funcational energy meter
2.Prepayment energy meter
3.Reactive energy meter
4.Watt-hour meter
5.Multi-rate watt-hour meters
6.Maximum demand energy meter.
7.Standard electric energy meter
1.Multi-funcational energy meter
2.Prepayment energy meter
3.Reactive energy meter
4.Watt-hour meter
5.Multi-rate watt-hour meters
6.Maximum demand energy meter.
7.Standard electric energy meter
2. Main Specifications and Technical Parameters
Display digits: 6-digit black character wheel. The word displays 0-9.
Number ratio: 200 :1
When the voltage is 5V±0.3V, the maximum frequency is 10Hz; the minimum pulse width is 50ms
Life: ≥2×10^7 number of driving pulses
DC impedance (20℃): 550Ω±50Ω
With character wheel protection cover
The total length of the exposed lead wire is 125±5mm
3. Technical Requirements
Comply with JB/T10666-2006 "Pulse Counter for Electric Energy Meter": shock and vibration resistance performance meet GB/T2423.5-1995, GB/T2423.10-1995 related requirements.
